G0505

The G0505 traction belt offers a balanced combination of flexibility and durability. Its 8 mm double cam profile with a relieving groove ensures reliable rod protection and added cam flexibility. Suitable for most general applications, this belt is designed to minimize wear on both the product and the belt components, while enabling slip-free drive when needed.

Pitch	Width	Strength	TB1	TB2	DB1	DB2	PH1	PH2	BD
35	50/60	900	14,7	16	18,5	15	8	8	7,9
40	60	900	18,6	17,3	19,5	19	8	8	7,9
44	60	900	22,6	16	19,5	24	8	8	7,9
45	60/120	900					8	8	7,9
50	50/60/120	900	28,6	16	19,5	30	8	8	7,9

Extra info	TN900	TN1000	TN1200
Strength per cm	-	-	-
recommended pretension (in %)	-	-	-
Elongation at break	-	-	-
Rubber ShoreA	-	-	-
Pitch tolerance	-	-	-
Belting width tolerance	-	-	-
Wear resistant (DIN 53516)	-	-	-
Moisture absorption	-	-	-

The G0505 combines protection, flexibility, and driving reliability in one design.

Double cam profile (8 mm) protects both rods and transported products.

Integrated relieving groove in the top cam improves belt flexibility and contouring.

Compatible with cam-driven systems (e.g., N, NC, and modular sprockets) to reduce the risk of slippage.

Ideal for applications where product safety and belt performance must go hand in hand.

At Broekema, we meticulously engineer our traction belts to ensure slip-free power transmission in agricultural and other demanding applications. Each belt is made from advanced rubber compounds formulated in-house within the Jäger Group, guaranteeing excellent wear resistance and a secure bond with the internal fabric layers. By using specialized fabric constructions, including pre-stretched warp threads, we reduce unwanted elongation so the belt’s cam pitch remains accurate over time.

We offer a range of fabric strengths, from TN900/3 (ideal for most general uses) and TN1000/2 (enhanced flexibility) to TN1200/3 (heavy duty). Choosing the right option involves striking a balance between tensile strength and maneuverability. For instance, while heavy-duty belts can handle substantial loads, they may be less flexible for tight corners or smaller roller diameters; on the other hand, a belt that’s too light might struggle under continuous heavy loads.

Another factor in maintaining belt longevity is the slight under-tolerance applied to the pitch during production. This allows installers to tension the belt precisely, aligning the cams correctly with the sprockets and minimizing premature wear. In practice, this means a more stable operation, fewer risks of slippage, and reduced downtime for maintenance or repairs.

Ultimately, choosing the right Broekema traction belt comes down to understanding your application’s specific needs—load requirements, environmental conditions, and the degree of bending in your setup. By matching the belt to these factors, you can achieve reliable performance, maximize service life, and keep your operation running smoothly.
